Casa ProdutosConector J30JJ30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment

J30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment

J30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment
J30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment
J30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment J30J Series 9-Pin Connector 250V 500VAC for Electronic Equipment
Informação Básica
Marca: Raymo
Certificação: CE/RoHs/REACH/ISO9001:2015
Model Number: RM-J30J
Documento: J30J Miniature Rectangular ...es.pdf
Minimum Order Quantity: 1 Piece
Preço: 5-15 USD
Packaging Details: CTN
Delivery Time: 3-4 Weeks
Termos de pagamento: T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000PCS Per Month
contacto
Classificação de tensão: 250V Tensão de suporte: 500VAC
Faixa de temperatura: -55 ̊+125 °C Comprimento do cabo: Conforme requer
Comprimento do fio: 50cm, 500mm Pinos disponíveis: 9, 15, 21, 25, 31, 37, 51, 66, 74, 100
Condutor central: Ligação de cobre, revestimento de ouro Aplicação: Equipamento eletrônico
Destacar:

J30J series 9-pin connector

,

250V 500VAC electronic connector

,

J30J series electrical equipment connector

J30J-9TJS 9 Pins J30J Series Connector ≤1.01X10-3 Pa.cm3/s Leak Rate

Designed for demanding electrical connection applications requiring durability and reliability.

Key Specifications
Attribute Value
Voltage Rating 250V
Withstanding Voltage 500VAC
Temperature Range -55～+125 ℃
Cable Length Customizable
Wire Length Options 50cm, 500mm
Available Pins 9, 15, 21, 25, 31, 37, 51, 66, 74, 100
Center Conductor Copper Alloy, Gold Plating
Primary Application Electronic Equipment
Product Overview

The J30J series connector features Micro Twist Pin Contact design for secure, stable connections in critical applications. With excellent insulation properties and wide temperature tolerance, it delivers reliable performance in challenging environments.

Technical Parameters
  • Mating Cycle: 500 Times
  • Grid Distance: 2.54*2.54
  • Leak Rate: ≤1.01X10-3 Pa.cm3/s
Industrial Applications
  • Industrial Machinery: Secure component connections for efficient machine operation
  • Aerospace Technology: Certified for CE, RoHs, REACH, and ISO9001:2015 compliance
  • Medical Equipment: Stable connections critical for patient safety
  • Automotive Electronics: High durability for demanding environments
  • Telecommunications: Reliable data transmission with customizable cable lengths
  • Robotics: Flexible installation options for optimal performance
Technical Support

Comprehensive product support available for technical inquiries, troubleshooting, and product-related assistance.
